Description
The 8-pin AM1U1108 is a programmable µASIC product that incorporates LUTs, Logic Macrocells, Timers, Oscillators. Its ultra-compact size and minimal power consumption (0.6µA) provide savings in both space and power.
Specifications
The 8-pin AM1U1108 is a programmable µASIC product that incorporates LUTs, Logic Macrocells, Timers, Oscillators. Its ultra-compact size and minimal power consumption (0.6µA) provide savings in both space and power.
Key features
- 1.71V to 5.5V Supply
- Operating Temperature Range: -40°C to 85°C
- Two Combinatorial 2-bit Look Up Tables (LUTs)
- Nine Multifunctional Macrocells
- Three 8-bit Timers
- Oscillator (25kHz/2MHz)
- Data protection feature (CRC, CRV)
